Preparing your LUBA 3 AWD for winter storage takes about 20–30 minutes and requires only a few basic tools. Before storing the mower, disable all scheduled mowing tasks, charge the battery to approximately 80%, thoroughly clean the mower and charging station, inspect key components for wear or damage, and allow everything to dry completely before storage.
If winter temperatures in your area regularly fall below -20°C (-4°F), move both the mower and charging station indoors to help protect sensitive electronic components and ensure reliable performance next season.
LUBA 3 AWD Winter Maintenance at a Glance
|
Item |
Details |
|
Time Required |
About 20–30 minutes |
|
Difficulty |
Easy |
|
Recommended Frequency |
Once before winter storage |
|
Suitable For |
Mammotion LUBA 3 AWD Series |
|
Tools Needed |
Soft brush, towel, lint-free cloth, low-pressure washer, WD-40, gloves, screwdriver |
Quick Tip: Before getting started, watch the step-by-step video below for a complete visual walkthrough. Then follow the written instructions to perform each maintenance task safely and thoroughly.
Why Robot Mower Winter Maintenance Matters
Taking 20–30 minutes to maintain your LUBA 3 AWD before winter storage can help keep it in excellent condition and reduce the risk of unexpected issues next season.
Here are the four main reasons why winter maintenance is important:
1. Prevent Dirt and Moisture from Causing Damage
Throughout the mowing season, grass clippings, mud, and moisture accumulate on the mower's body, cutting system, wheels, and charging contacts. Cleaning the mower before storage helps reduce the risk of corrosion, prevents debris from hardening over the winter, and keeps moving parts operating smoothly.
2. Protect the Battery During Long-Term Storage
Before storing your LUBA 3 AWD, charge the battery to approximately 80% and disable all scheduled mowing tasks in the Mammotion app. Proper battery preparation helps ensure the mower is ready for storage and avoids unnecessary battery drain during extended periods of inactivity.
3. Identify Worn or Damaged Components Early
Winter maintenance is also a good opportunity to inspect important components, including the cutting blades, lifting seal sleeve, front bumper, and guard bracket. Replacing worn or damaged parts before the next mowing season can reduce unexpected downtime and improve overall reliability.
4. Ensure a Faster, Smoother Start Next Season
A clean and properly stored mower is ready to return to work as soon as the growing season begins. Spending a little time on maintenance before winter can help reduce spring preparation, minimize maintenance issues, and extend the service life of your LUBA 3 AWD.
Tools You'll Need Before You Start
Before you begin, gather the following tools to make the maintenance process easier and safer. Most of these are common household items, and no specialized repair equipment is required.
|
Tool |
Purpose |
|
Soft brush |
Remove grass clippings, mud, and loose debris from the mower and charging station. |
|
Towel or microfiber cloth |
Wipe down the mower's exterior after cleaning. |
|
Lint-free cloth |
Clean the LiDAR module, 3D Vision module, charging contacts, and infrared sensors without leaving residue. |
|
Low-pressure washer |
Rinse the mower's underside and wheels after brushing away dirt. |
|
WD-40 |
Clean and protect the front bumper's connecting ports. |
|
Gloves |
Protect your hands when handling the cutting discs and blades. |
|
Screwdriver |
Remove and reinstall the front bumper and cutting discs. |
Important: Never use a high-pressure washer to clean your LUBA 3 AWD. High-pressure water can force moisture into seals, bearings, electrical connectors, and sensitive sensors, potentially causing damage. Always use a soft brush together with a low-pressure water spray when cleaning the mower.
Step-by-Step Guide to Winterizing Your LUBA 3 AWD
Watch the video below for a complete visual walkthrough before you begin. Then follow the written instructions to clean, inspect, and prepare your LUBA 3 AWD for winter storage.
Before You Begin
Before starting maintenance, keep these safety precautions in mind:
- Perform maintenance in a clean, dry, and well-ventilated area.
- Wear protective gloves when handling the cutting discs and blades.
- Make sure the mower is powered off and the security key has been removed before servicing.
- Use only a soft brush and a low-pressure washer for cleaning. Never use a high-pressure washer.
Step 1. Prepare Your LUBA 3 AWD for Maintenance
Estimated Time: 2 minutes
What You'll Do
Complete the following preparation steps before cleaning or inspecting the mower:
- Disable all scheduled mowing tasks in the Mammotion app.
- Charge the battery to approximately 80%.
- Turn on the mower.
- Double-press the Cutting button to lower the cutting discs to the lowest position.
- Power off the mower.
- Remove the security key.
Why This Step Matters
Preparing the mower correctly makes the maintenance process safer, prevents accidental startup, and places the battery in an appropriate condition for long-term winter storage.
Important: If winter temperatures regularly fall below -20°C (-4°F), plan to store both the mower and the charging station indoors after maintenance is complete.
Step 2. Clean the Robot Mower Exterior
Estimated Time: 3–5 minutes
What You'll Do
Clean the mower's exterior to remove dirt, grass residue, and dust that accumulated during the mowing season.
- Wipe the entire mower body using a damp towel or soft brush.
- Clean the LiDAR module, 3D Vision module, and charging contacts with a clean lint-free cloth.
- Remove fingerprints, dust, and water spots from all sensor surfaces.
Why This Step Matters
Keeping the exterior clean helps protect sensitive sensors and charging components during storage while ensuring reliable navigation and charging performance when the mower is used again.
Step 3. Remove and Clean the Front Bumper
Estimated Time: 3 minutes
What You'll Do
Clean the front bumper assembly and its connection points.
- Remove the connecting screws and detach the front bumper.
- Clean the bumper and the connecting ports.
- Apply a small amount of WD-40 to the connecting ports if needed.
- Reinstall the bumper and tighten all screws securely.
Why This Step Matters
Cleaning the bumper helps remove trapped dirt and moisture around the connection points, reducing the chance of corrosion during long-term storage.
Step 4. Clean the Underside and Cutting System
Estimated Time: 10–12 minutes
What You'll Do
This is the most important part of winter maintenance, as the underside collects the most dirt and grass buildup.
- Put on protective gloves.
- Place the mower on a washing stand or carefully turn it upside down on a stable surface.
- Place a soft towel beneath the LiDAR module to protect it from scratches or accidental impact.
- Remove the fixing screws and cutting discs.
- Inspect the blades and replace any that are worn, damaged, or corroded.
- Remove grass clippings, mud, and debris from the underside.
- Clean the underside using a soft brush and a low-pressure washer.
- Clean the front and rear wheels using the same method.
- Wipe the LiDAR module and 3D Vision module with a dry lint-free cloth.
- Allow the mower to air dry for at least 30 minutes.
- Reinstall the cutting discs after the mower is completely dry.
Why This Step Matters
Grass clippings and mud can trap moisture over the winter, potentially leading to corrosion or affecting moving parts. Thorough cleaning also gives you the opportunity to inspect the blades and cutting system before storing the mower.
Important: Never use a high-pressure washer. High-pressure water can damage seals, bearings, sensors, electrical connectors, and other sensitive components.
Step 5. Inspect Key Components
Estimated Time: 2 minutes
What You'll Do
Perform a final inspection before putting the mower into storage.
- Check the lifting seal sleeve for cracks, wear, or other damage.
- Inspect the guard bracket screws and tighten them if necessary.
- Confirm that all cutting discs and fasteners are securely installed.
Why This Step Matters
Identifying worn or loose components before storage helps prevent unexpected maintenance issues and ensures the mower is ready for the next mowing season.
Important: If the lifting seal sleeve is damaged, contact Mammotion After-sales Service before operating the mower again.
Step 6. Clean and Store the Charging Station
Estimated Time: 3–5 minutes
What You'll Do
Prepare the charging station for winter storage.
- Use a peg wrench to remove the ground screws securing the charging station.
- Remove mud, grass, and debris from the charging station base.
- Wipe the infrared lens and charging contacts with a clean lint-free cloth.
- If temperatures regularly fall below -20°C (-4°F), move both the charging station and power supply indoors for the winter.
Why This Step Matters
A clean charging station helps maintain reliable charging performance and protects electrical components during extended periods of storage.
Common Winter Maintenance Mistakes to Avoid
Most winter maintenance issues are easy to prevent with proper care. Avoid these common mistakes to help protect your LUBA 3 AWD during long-term storage and ensure it's ready for the next mowing season.
Winter Maintenance Mistakes at a Glance
|
Avoid This |
Do This Instead |
|
Use a high-pressure washer |
Use a soft brush and a low-pressure washer |
|
Store the mower while it's still wet |
Let the mower dry completely before storage |
|
Skip blade inspection |
Replace worn or damaged blades before storage |
|
Ignore dirty charging contacts |
Clean the charging contacts with a lint-free cloth |
|
Store equipment in harsh winter conditions |
Store it in a clean, dry location and bring it indoors below -20°C (-4°F) |
Using a High-Pressure Washer
A high-pressure washer may seem like the fastest way to remove mud and grass clippings, but it can force water into seals, bearings, electrical connectors, and sensitive components such as the LiDAR and 3D Vision modules.
Instead: Use a soft brush together with a low-pressure washer to clean the mower safely.
Storing the Mower Before It's Completely Dry
Moisture trapped inside or underneath the mower can contribute to corrosion during long periods of storage.
Instead: After cleaning, leave the mower upright for at least 30 minutes and make sure all components are completely dry before storing it.
Forgetting to Inspect the Blades
Worn, bent, or corroded blades can reduce cutting performance and may need to be replaced before the next mowing season.
Instead: Inspect the blades while the cutting discs are removed, and replace any damaged or heavily worn blades before storage.
Leaving Dirt on the Charging Contacts
Grass residue, dust, or oxidation on the charging contacts can interfere with charging performance after winter.
Instead: Wipe the charging contacts on both the mower and the charging station with a clean lint-free cloth before storing the equipment.
Storing the Equipment in Unsuitable Conditions
Leaving the mower or charging station in areas exposed to extreme cold, excessive humidity, or direct weather conditions can increase the risk of damage during winter.
Instead: Store the equipment in a clean, dry location. If temperatures regularly fall below -20°C (-4°F), move both the mower and the charging station indoors.
LUBA 3 AWD Winter Storage Checklist
Before putting your LUBA 3 AWD away for the winter, use this checklist to make sure all essential maintenance tasks have been completed.
|
✔ Checklist |
Status |
|
Scheduled mowing tasks have been disabled in the Mammotion app. |
☐ |
|
Battery has been charged to approximately 80%. |
☐ |
|
Security key has been removed before maintenance. |
☐ |
|
Mower exterior has been cleaned. |
☐ |
|
LiDAR module, 3D Vision module, and charging contacts have been cleaned with a lint-free cloth. |
☐ |
|
Front bumper has been removed, cleaned, and reinstalled securely. |
☐ |
|
Underside, cutting system, and wheels have been thoroughly cleaned. |
☐ |
|
Cutting blades have been inspected and replaced if necessary. |
☐ |
|
Lifting seal sleeve and guard bracket screws have been checked. |
☐ |
|
Mower has dried completely before storage. |
☐ |
|
Charging station and charging contacts have been cleaned. |
☐ |
|
Mower and charging station have been stored in an appropriate environment. |
☐ |
Storage Tips
For the best storage conditions during the off-season:
- Store the mower in a clean, dry, and well-ventilated location.
- Keep the mower away from direct rain, snow, and excessive humidity.
- If temperatures regularly fall below -20°C (-4°F), store both the mower and charging station indoors.
- Before using the mower again in spring, perform a quick visual inspection and make sure all components are clean and securely installed.
If you have any questions regarding winter maintenance for the LUBA 3 AWD, please contact Mammotion.
