Mammotion LUBA 2 AWD X Overview
The Mammotion LUBA 2 AWD X Series is a lineup of wire-free, all-wheel-drive robotic lawn mowers introduced in 2025. Designed for residential lawns, the series combines autonomous mowing, intelligent navigation, and app-based lawn management to help homeowners reduce manual lawn care.
The LUBA 2 AWD X Series includes different model configurations for varying lawn sizes and cutting-height requirements. When comparing models, consider your total mowing area, terrain, preferred grass height, and the features you need.
This guide covers the LUBA 2 AWD X model lineup, technical specifications, key technologies, user manuals, and maintenance resources.
Availability in the United States: The LUBA 2 AWD X Series is no longer available for purchase through Mammotion's US store. Existing owners can continue to access the official LUBA 2 AWD X Series support center for product documentation and assistance.
Exploring the LUBA 3 AWD Upgrade
Although the LUBA 2 AWD X Series is no longer available through Mammotion's US store, its all-wheel-drive performance, wire-free operation, and intelligent lawn management remain useful reference points for understanding Mammotion's robotic mower lineup.
For homeowners considering a newer model, the LUBA 3 AWD introduces Tri-Fusion Navigation, which combines 360° LiDAR, NetRTK, and dual-camera AI vision, along with upgraded AI processing and additional intelligent mowing features.
Want to understand the differences in more detail? Read our guide to LUBA 3 AWD vs. LUBA 2 AWD: Key Upgrades and What's New, or explore the Mammotion LUBA 3 AWD robot lawn mower for current models and features.
Mammotion LUBA 2 AWD X Model Lineup
The LUBA 2 AWD X Series robot mowers include the 3000X, 5000X, and 10000X models, along with corresponding HX versions for users who need a higher cutting range. The main difference between the X and HX versions is their cutting-height range.
| Model | Version | Cutting Height | Maximum Mowing Area |
|---|---|---|---|
| LUBA 2 AWD 3000X | Standard | 1–2.7 in | 3,000 m² |
| LUBA 2 AWD 5000X | Standard | 1–2.7 in | 5,000 m² |
| LUBA 2 AWD 10000X | Standard | 1–2.7 in | 10,000 m² |
| LUBA 2 AWD 3000HX | High | 2.2–4 in | 3,000 m² |
| LUBA 2 AWD 5000HX | High | 2.2–4 in | 5,000 m² |
| LUBA 2 AWD 10000HX | High | 2.2–4 in | 10,000 m² |
The listed lawn-area category provides a starting point for comparing models. Actual mowing capacity can depend on terrain, grass growth, mowing schedules, and other operating conditions. Check the specifications for your exact model before making a decision.
Regional availability: HX models are available in the United States and Canada, according to the supplied product information. Availability may vary by market.
Mammotion LUBA 2 AWD X Specifications
The following table summarizes the supplied specifications for the LUBA 2 AWD X Series. Use it to compare model classes, cutting options, battery capacity, and other listed features.
| Specification | 10000X / 10000HX | 5000X / 5000HX | 3000X / 3000HX |
|---|---|---|---|
| Maximum Mowing Area | 10,000 m² | 5,000 m² | 3,000 m² |
| Positioning & Navigation System | NetRTK + Dual Camera AI Vision | NetRTK + Dual Camera AI Vision | NetRTK + Dual Camera AI Vision |
| 4G Service | Free 4G Module with 1-Year Data | Free 4G Module with 1-Year Data | Free 4G Module with 1-Year Data |
| Maximum Multi-Zone Management | 100 zones | 50 zones | 30 zones |
| Maximum Climbing Ability | 80% (38.6°) | 80% (38.6°) | 80% (38.6°) |
| Drive System | All-wheel drive (AWD) | All-wheel drive (AWD) | All-wheel drive (AWD) |
| Battery Capacity | 15 Ah | 12 Ah | 12 Ah |
| Cutting Width | 400 mm | 400 mm | 400 mm |
| Cutting Height — X | 1–2.7 in | 1–2.7 in | 1–2.7 in |
| Cutting Height — HX | 2.2–4 in | 2.2–4 in | 2.2–4 in |
| Cutting Disc | 2 | 2 | 2 |
| Cutting System | 6 pivoting razor blades per disc | 6 pivoting razor blades per disc | 6 pivoting razor blades per disc |
| Cutting Disc Motor Power | 165 W | 165 W | 165 W |
| Mowing Area per Charge | 1,500 m² | 1,200 m² | 1,000 m² |
| Charging Time | 150 min | 120 min | 120 min |
| Mowing Time per Charge | 240 min | 190 min | 190 min |
| Dimensions (L × W × H) | 690 × 513 × 273 mm | 690 × 513 × 273 mm | 690 × 513 × 273 mm |
| Net Weight | 19.1 kg | 18.6 kg | 18.6 kg |
| Connectivity | Bluetooth, Wi-Fi & 4G | Bluetooth, Wi-Fi & 4G | Bluetooth, Wi-Fi & 4G |
| Waterproof Rating | IPX6 | IPX6 | IPX6 |
Specifications and service terms may vary by model or region. Confirm the figures for the exact LUBA 2 AWD X configuration using the official Mammotion product documentation before relying on them.
The X and HX versions share the same listed lawn-area categories within each model class, but their cutting-height ranges differ. The standard X version is suited to shorter cutting heights, while the HX version accommodates taller grass.
Mammotion LUBA 2 AWD X Features and Technology
The Mammotion LUBA 2 AWD X robotic mowers combine all-wheel-drive performance, NetRTK positioning, dual-camera AI vision, and app-based lawn management. Its wire-free operation and configurable mowing tasks are designed to help homeowners manage complex residential lawns without installing traditional perimeter wires.
All-Wheel Drive for Sloped and Uneven Lawns
The LUBA 2 AWD X robot mower features an all-wheel-drive (AWD) system designed to navigate sloped lawns and varied terrain. By powering all four wheels, the mower is built to maintain traction while moving across challenging lawn conditions.
With a rated maximum climbing ability of 80% (38.6°), the LUBA 2 AWD X is designed for properties where slope performance is an important consideration. Actual performance can depend on surface traction, grass conditions, moisture, and terrain configuration.
NetRTK and Dual-Camera AI Vision Navigation
The LUBA 2 AWD X combines NetRTK positioning with dual-camera AI vision to support autonomous navigation and mowing. NetRTK provides satellite-based positioning corrections through a network service, while camera-based vision supplies additional information about the mower's surroundings.
Where the iNavi NetRTK service is supported and available, users can access high-precision positioning without installing a physical RTK reference station on their property. Service availability and positioning performance may vary with regional coverage and local conditions. Check the official iNavi Service information to confirm coverage in your area.
Perimeter-Wire-Free Mowing and Automatic Mapping
The LUBA 2 AWD X robotic mower is designed for perimeter-wire-free lawn management. Rather than requiring traditional boundary wires around the lawn, it uses positioning and mapping capabilities to establish mowing areas digitally.
Automatic mapping helps users create virtual lawn boundaries and configure separate mowing areas. This can simplify lawn setup and provide flexibility for properties with front and back lawns, side yards, and other distinct sections.
Mapping accuracy and navigation performance can vary with property layout, satellite visibility, and surrounding obstacles. Refer to the official user manual for mapping procedures and recommended operating conditions.
UltraSense AI Vision and Obstacle Recognition
UltraSense AI Vision helps the mower recognize objects and interpret its surroundings during operation. This visual information supports obstacle handling and helps the mower distinguish between mowable areas and objects that should be avoided.
Obstacle recognition can be useful on residential lawns where toys, garden objects, pets, or other obstacles may be present. However, it should not be treated as a guarantee that every object will be detected or avoided in every situation. Users should keep the mowing area appropriately prepared and follow the manufacturer's safety guidance.
Multi-Zone Lawn Management
The LUBA 2 AWD X supports multi-zone lawn management, allowing users to organize separate lawn sections instead of treating an entire property as one continuous mowing area. This is useful for properties with front and back lawns, side yards, or other distinct mowing areas.
Supported zone capacity varies by model. Refer to the model specifications above for the maximum number of mowing zones supported by each configuration.
Intelligent Mowing Paths and 3D Lawn Printing
The LUBA 2 AWD X supports planned mowing routes and customizable lawn patterns through compatible mowing settings. These options help users organize mowing tasks and personalize the appearance of their lawns.
Mammotion's 3D Lawn Printing feature lets users create selected patterns as part of their mowing design. Available patterns and task settings may depend on app functionality and software version.
App Control and 4G Connectivity
The LUBA 2 AWD X supports Bluetooth, Wi-Fi, and 4G connectivity for compatible app-based controls and remote mower management. Depending on connectivity and service availability, users can manage supported mowing tasks, review device information, and access remote functions through the Mammotion app.
The 2025 LUBA 2 AWD X product offering includes a 4G module with one year of data under Mammotion's stated service terms. Consult Mammotion's official 4G Service information for applicable terms rather than assuming that a particular data plan applies to every unit.
Anti-Theft Protection and GPS Tracking
The LUBA 2 AWD X includes features designed to help owners monitor their mower and manage device access. Available features include GPS location tracking, ownership authentication, app notifications, and compatibility with an optional Apple AirTag.
- GPS Tracking: Check the mower's reported location through the Mammotion app, subject to connectivity and location-service availability.
- Ownership Authentication: The main user can activate the device and grant access to other authorized users.
- App Notifications: Supported alerts can notify users about certain mower status or location events.
- Apple AirTag Compatibility: Owners can add an AirTag as an additional tracking option. An Apple AirTag is sold separately and is not included with the mower.
These features provide additional monitoring options but should not be considered a guarantee against theft or loss. Refer to the official documentation for setup instructions and feature limitations.
Mammotion LUBA 2 AWD X Manuals and Maintenance
For help with setup, everyday operation, and seasonal care, owners can refer to Mammotion's official LUBA 2 AWD X documentation and maintenance resources.
LUBA 2 AWD X User Manual
The official LUBA 2 AWD X Series user manual provides product-specific instructions for operating and maintaining the mower. It is a useful reference for owners who need guidance on setup, app controls, mowing tasks, and troubleshooting.
Read the official LUBA 2 AWD X Series User Manual.
LUBA 2 AWD X Winter Maintenance
Preparing a robotic lawn mower for winter storage helps owners follow the manufacturer's recommendations during periods when regular mowing is not required. Before storing your LUBA 2 AWD X, consult Mammotion's official winter maintenance instructions for model-appropriate cleaning, battery care, and storage guidance.
Refer to Mammotion LUBA 2 AWD X Winter Maintenance.
Need additional help with your LUBA 2 AWD X robot lawn mower? Contact Mammotion Official Customer Service.
Mammotion LUBA 2 AWD X FAQ
No. The LUBA 2 AWD uses virtual boundaries and automatic mapping, so users do not need to install a traditional perimeter wire. Mapping and navigation performance may depend on lawn conditions and the available positioning services.
Not necessarily. Compatible LUBA 2 AWD X models support Mammotion iNavi Service™ (NetRTK), which can provide high-precision positioning without installing a physical RTK base station where the service is available. Check the official iNavi Service information to confirm coverage in your area.
The number of supported mowing zones depends on the model:
- LUBA 2 AWD 3000X / 3000HX: up to 30 zones
- LUBA 2 AWD 5000X / 5000HX: up to 50 zones
- LUBA 2 AWD 10000X / 10000HX: up to 100 zones
The LUBA 2 AWD X Series is no longer available for purchase through Mammotion's US store. Existing owners can still consult Mammotion's official support resources for product documentation and assistance.
If you are exploring a current-generation option, visit the official Mammotion US website to learn more about the LUBA 3 AWD Series.
The main difference between the LUBA 2 AWD X and HX versions is their cutting-height range:
- X (Standard Version): Cutting height of 1–2.7 inches.
- HX (High Version): Cutting height of 2.2–4 inches.
Other than cutting height, the X and HX versions share the same listed specifications within the corresponding 3000, 5000, or 10000 model class. HX versions are sold in the United States and Canada.
The supplied specifications list Bluetooth, Wi-Fi, and 4G connectivity, along with a free 4G module and one year of data. Check the current regional product listing and service terms to confirm the applicable data plan and any conditions after the included period. Details about Mammotion 4G Service.
Rated mowing time varies by model:
- LUBA 2 AWD 10000X / 10000HX: Up to 240 minutes per charge
- LUBA 2 AWD 5000X / 5000HX: Up to 190 minutes per charge
- LUBA 2 AWD 3000X / 3000HX: Up to 190 minutes per charge
These are specification figures rather than a guarantee of real-world output. Actual mowing time and area can vary with the lawn, terrain, route, grass conditions, and settings.
